SS ASTM A240 347 Plate, 347L Stainless Steel Chequered Plate Stockists, Stainless Steel 347 Shim Plate, SS 347L CR Plate, Stainless Steel 347 Hot Rolled Plate Manufacturer in India
Surya Steel is a reputed Stainless Steel 347/347L Plate Manufacturer in India with a track record of manufacturing high-quality Stainless Steel 347 Plate that are of high standards in terms of their use in the industry. Both cold roll and hot roll processes are performed on our Plate, making them have the utmost strength, durability, and surface finish. Our SS 347L Cr Plate, which is manufactured and supplied to meet the ISO and international standards, is finished as ASME A240 Stainless Steel 347L Plate, which is applicable in critical applications. We also have SS 347/347L Perforated Plate, which is needed by industries that require high precision and will be used for a long time. In Surya Steel, we apply high and advanced technology to guarantee the quality and reliability of supply in the global markets.
Stainless Steel 347L Finish Plate, SS 347/347L Plate, ASTM A240 Stainless Steel 347/347L Plate Supplier, ASTM A240 Stainless Steel 347 Plate Exporter, SS 347/347L Perforated Plate Supplier in India
Surya Steel is an acknowledged Stainless Steel 347/347L Plate Manufacturer and Supplier in India, and its manufacturing has high industrial standards. We utilize the best manufacturing materials in the manufacturing of our ASTM A240 Stainless Steel 347 Plate, such as stabilized austenitic stainless steel that contains niobium and titanium to improve its corrosion resistance. We supply Stainless Steel 347/347L Plate at the lowest price with great quality and thus its reliability in different industries. The Plate come in various tempers, and they are flexible in their uses in Chemical, Petrochemical, and Power Generation Industries. Since it is committed to excellence, Surya Steel remains a reliable source of global stainless steel needs. We are also a major Stainless Steel 904L Plate Manufacturer in India.
Specifications of Stainless Steel 347/347L Plate
| Stainless Steel 347 & 347L | Specifications |
| Dimensions | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finishing | Hot rolled plate (HR), Cold rolled Plate (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc. |
| Form | Coils, Foils, Rolls, Plain Plate, Shim Plate, Perforated Plate, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Other Grades of Stainless Steel Plate
Stainless Steel 347 Plate Equivalent Grade
| STANDARD | UNS | WNR. | JIS | EN |
| SS 347 | S34700 | 1.4550 | SUS 347 | X6CrNiNb18-10 |
| SS 347L | S34709 | 1.4961 | SUS 347H | X6CrNiNb18-12 |
Stainless Steel 347/347L Plate Physical Properties
| Units | Temperature in °C |
| Density | 7.97 g/cm³ |
| Specific Heat | 0.12 Kcal/kg.C |
| Melting Range | 1398 – 1446 °C |
| Modulus of Elasticity | 193 KN/mm² |
| Electrical Resistivity | 72 µΩ.cm |
| Coefficient of Expansion | 16.0 µm/m °C |
| Thermal Conductivity | 16.3 W/m -°K |
| Annealed | 1040 – 1100 (°C) / 1900 – 2000 (°F) |
| Quenched | Rapid Air/Water |
SS 347 & 347L Plate Chemical Composition
| C | Cr | Mn | Ni | P | S | Si | Cb/Ta | |
| 347 | 0.08 max |
min: 17.0 max: 20.0 |
2.0 max |
min: 9.0 max: 13.0 |
0.04 max |
0.30 max |
0.75 max |
min:10x C max: 1.0 |
| 347L |
min: 0.04 max: 0.10 |
min: 17.0 max: 20.0 |
2.0 max | min: 9.0 max: 13.0 |
0.03 max | 0.30 max |
0.75 max |
min:10x C max: 1.0 |
Stocking Distributors of below leading Manufacturer of Stainless Steel 347/347L Plate
 |
|
|
 |
|---|---|---|---|
 |
 |
 |
 |
Applications of Stainless Steel 347/347L Plate
- Petrochemicals Industry
- Food Industries
- Oil & Gas Industries
- Automotive Industry
- Pharmaceuticals Industry
- Sugar Mills
- Solar Energy System
- Cement Plants
- Textile Industries
Stainless Steel 347/347L Plate Manufacturer, Supplier and Exporter in India Surya Steel
