Surya Steel is a highly acclaimed stainless steel patta and patti Manufacturer in India, supplying superior SS 304 patta and patti from high-quality Stainless Steel 304. The material is first cast into billets and then hot rolled or extruded into the desired shape, followed by cold rolling to achieve precise thickness tolerance and a smooth surface. Our SS Patta & Patti are available in sizes ranging from 10 mm to 2000 mm in width, with thicknesses from 1 mm to 100 mm, ensuring versatility for various industrial applications. Each product undergoes rigorous quality checks, including size measurements and chemical tests, before being cut and packaged for supply.
Surya Steel is a prominent stainless steel patta and patti Manufacturer and supplier in India. The aim is to supply SS 304 Patta & Patti that withstand harsh environments, possess high tensile strength, and long life span to meet the industrial requirements. The new target aims at guaranteeing that the fabricated products have consistent quality, accurate dimensions, and fast production time in adherence to the requirements of customers in industries that include construction, automotive, and food industries.
SS Patta Supplier, ASTM A240 Stainless Steel Patti, 316 Stainless Steel Patta Stockist, SS Patti Exporter, SS Patti Supplier in India
Surya Steel is remarkable Stainless Steel Patta & Patti Supplier in India. SS Patta & Patti have excellent chemical and mechanical properties. The chemical composition of SS 304 is composed of 18 up to 20% chromium and 8 up to 10.5% nickel which gives the material excellent resistance to many corrosive environments while the addition of molybdenum in SS 316 supply an extra level of protection against pitting and crevice corrosion making it suitable for marine environment and chemical processing applications respectively. From a mechanical perspective, both grades show high-elevated tensile strength, excellent ductility, and high-temperature resistance, which guarantees the necessary structural stability, ease of fabrication, and long-term functional solutions for demanding applications. We are also leading Stainless Steel Slitting Coils Manufacturer in India.
Specifications of Stainless Steel Patta & Patti
| Stainless Steel Patta & Patti | Specifications |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Thickness | 1 mm To 100 mm |
| Diameter | Upto 2000 mm |
| Hardness | HRB 62 to 180 - HV 140 to 1250 |
| Cutting | Plasma & Machined Cut |
| Finish | HR, CR, 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Edge | Mill Edge, Slit Edge |
Grades of Stainless Steel Patta & Patti
Chemical Composition of Stainless Steel Patta & Patti
| AISI ASTM | EN DIN | C % Max | Mn % Max | Si % Max | S % Max | P % Max | Cr % Max | Ni % Max | Mo % Max | Others % |
| 202 | - | 0.15 | 7.5-10 | 1.00 | 0.030 | 0.060 | 17.00-19.00 | 4.00-6.00 | - | - |
| 304 | 1.4301 | 0.08 | 2.00 | 1.00 | 0.030 | 0.045 | 18.00-20.00 | 8.00-11.00 | - | - |
| 304L | 1.4306 | 0.03 | 2.00 | 1.00 | 0.030 | 0.045 | 18.00-20.00 | 8.00-12.00 | - | - |
| 310 | 1.4841 | 0.25 | 2.00 | 1.50 | 0.030 | 0.045 | 24.00-26.00 | 19.00-22.00 | - | - |
| 310S | 1.4842 | 0.08 | 2.00 | 1.50 | 0.030 | 0.045 | 24.00-26.00 | 19.00-22.00 | - | - |
| 316 | 1.4401 | 0.08 | 2.00 | 1.00 | 0.030 | 0.045 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | - |
| 316L | 1.4404 | 0.03 | 2.00 | 1.00 | 0.030 | 0.045 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | - |
| 316Ti | 0.08 | 2.00 | 1.00 | 0.030 | 0.045 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | Ti : Min (5xC%) | |
| 317L | 1.4438 | 0.03 | 2.00 | 1.00 | 0.030 | 0.045 | 18.00-20.00 | 11.00-15.00 | 3.00-4.00 | N : 0.10-0.22 |
| 321 | 1.4541 | 0.08 | 2.00 | 1.00 | 0.030 | 0.045 | 17.00-19.00 | 9.00-12.00 | - | Ti : Min (5xC%) |
| 347 | 1.4006 | 0.15 | 1.00 | 1.00 | 0.030 | 0.040 | 11.50-13.50 | - | - | - |
| 904L | 1.4057 | 0.20 | 1.00 | 1.00 | 0.030 | 0.040 | 15.00-17.00 | 1.25-2.50 | - | - |
Mechanical Properties of Stainless Steel Patta & Patti
| Grade | Type | Tensile Strength (MPa) | Yield Strength (0.2% YS) (MPa) | Elongation (%) | Hardness (HBW) |
| 304 | Austenitic | 515–750 | 205 | 40 | 160–190 |
| 304L | Austenitic (Low Carbon) | 485–700 | 170 | 40 | 150–180 |
| 316 | Austenitic (Mo Added) | 515–760 | 205 | 40 | 150–190 |
| 316L | Austenitic (Low Carbon) | 485–735 | 170 | 40 | 150–180 |
| 321 | Austenitic (Ti Stabilized) | 515–750 | 205 | 40 | 160–190 |
| 310 / 310S | Austenitic (High Temp) | 520–760 | 205 | 40 | 150–190 |
| 410 | Martensitic | 450–650 | 275 | 20 | 180–223 |
| 202 | Martensitic | 700–850 | 350 | 15 | 200–250 |
| 440 | Ferritic | 450–600 | 205 | 22 | 152 |
| 316Ti | Ferritic (High Cr) | 380–550 | 275 | 25 | 140–170 |
| 904L | Austenitic (High Ni-Mo-Cu) | 490–690 | 220 | 35 | 150–190 |
| 17-4 PH | Precipitation Hardening | 1100–1310 | 1000 (H900) | 10–20 | 331–388 |
Applications of Stainless Steel Patta & Patti
- Petrochemicals Industry
- Food Industries
- Oil & Gas Industries
- Automotive Industry
- Pharmaceuticals Industry
- Sugar Mills
- Solar Energy System
- Cement Plants
- Textile Industries
